Battery Powered Abrasive Blasting Booth Rail Guided Cart

Load Capacity: 1-1500 tons

Speed: 20 m/min or as your needs

OEM&ODM: Support

Motors: PMAC / AC high efficiency motors

Wheels: Cast Steel Polyurethane Rubber Wheel

Advantage: peculiar set-up makes the transfer cart save cost and operate more

Description

                         Battery Powered Abrasive Blasting Booth Rail Guided Carrier

Product description

The working principle of BDG series electric flat car is as follows: the AC 380V power supply is stepped down to the AC 36V two-phase through the transformer and connected to the two rails respectively….

Description

The working principle of BDG series electric flat car is as follows: the AC 380V power supply is stepped down to the AC 36V two-phase through the transformer and connected to the two rails respectively. The wheels on the track flat car introduce the AC 36V power supply on the track into the vehicle electrical equipment. The box, through the rectifier module, rectifies the AC 36V to DC 36V and then controls the DC motor through the DC control system to make the flat start, stop, advance, retreat, speed regulation and so on.

Advance

This series of flat cars can be used in S-type track, curved track, and high temperature. The flat car can be equipped with the car console and pedal. It can also be equipped with hydraulic lifting system and automatic control. The flat-car DC motor has the advantages of stable starting, large starting torque, small impact on the reducer, low voltage and long service life.

Application

ladle transfer cartThis series of flat cars have safety and maneuverability and has high requirements for track laying (requires insulation treatment track). It is suitable for transportation with low load capacity (≤60t), high frequency of use and medium and long-distance transportation. Not limited by distance, but the running distance is more than 70 meters, the number of transformers needs to be increased to compensate for the track pressure drop.

Parameters



 Model BXC-2t BXC-20t  BXC-50t BXC-100t BXC-150t c82da5b481c6f4ed83960019314a66c
 Rated Load(t)      2 20 50 100 150
Wheel Base(mm)  1200     2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 1435 2000
Wheel Diameter 270    350 500 600 600
Wheel Quality 4 4 4 4 8
Ground Clearance (mm) 50 50 50 75 75
Running Speed (min) 0-25 0-20 0-20 0-20 0-18
Motor Power (kw) 1 2.2 5 10 15
Battery Capacity 180 180 330 440 600
Battery Voltage 24 48 48 72 72
Running Time When Full 4.32 4 3.3 3.2 2.9
Running Distance for one Charge (Km) 6.5 4.8 4 3.8 3.2
Max Wheel Load 14.4 77.7 174 343.8 265.2
Reference Weight (t) 2.8 5.9 8 14.6 26.8
Recommend Rail Model P15 P24 P43 QU100 QU100











Process

  • 360 degree motorized rotation without causing any damage to the floor.

  • Powered by storage battery, turning freely without any cable strings.

  • Controlled easily by pressing the buttons and speed controller.

  • High level automation(self propelled/steerable)

  • The largest capacity can reach to 100t

  • Safe parts are installed in the transfer cart(warning light, e-stop, buffer...)

  • Robust sturdy car frame

Notes

  • 1 Load capacity ,table size and rail gauge can be customized
  • 2 Options : Remote radio control (imported or made in China )
  • 3 Automatic stop when detecting obstacle or person ,limit switches (to limit travel)
  • 4 Battery type ( Free of maintenance battery ,lithium battery ,explosion -proof battery ,and Anti -high temperature battery )
  • 5 motor (DC motor with brush and DC motor brushless )
  • 6 Electrical parts (imported or made in china )

Hot Products

Get A Free Quote

Please feel free to give your inquiry in the form below .We will reply you in 24 hours .

  • Load Capacity:
  • Whether car is self -propelled:
                                                                 If yes ,the power is from:
  • Table size:
  • Traveling distance:
    Use Place:
  • Name*:
    Email*:
  • Phone:
    Country:
  • Message:

Application

The battery powered abrasive blasting booth rail guided cart is widely used to transfer heavy cargoes of steel tube and pipes, coiled sheets and plates, steel bars, machine manufacturing pieces, metal forging and casting pipeces, steel coils, building structural materials, galvanized coils and aluminum coils, other metal and steel heavy cargoes.

The battery powered abrasive blasting booth rail guided cart has a large load range from 1t to 300t. According to customer's special requirements, specific load ability is designed. And also, different table shape is designed according to different cargo shapes, for example coil car, ladle car, scissor lifting table cargo, etc.
